General Cable 5131361E
General Cable GenSPEED 5000 5131361E CMP UTP Cat 5e Plenum Cable, Pull-Pac Packaging, (4 Pairs) 24 AWG Annealed Bare Solid Copper Conductor, 1000 ft L
General Cable 5131361E
General Cable GenSPEED 5000 5131361E CMP UTP Cat 5e Plenum Cable, Pull-Pac Packaging, (4 Pairs) 24 AWG Annealed Bare Solid Copper Conductor, 1000 ft LOut of Stockmore info
|
Out of Stockmore info
|
Product Description
General Cable GenSPEED 5000 Cable, CMP UTP Cat 5e Plenum, Pull-Pac Packaging, 4 Pairs Conductors, Annealed Bare Solid Copper Conductor, 24 AWG Conductor, 0.18 in OD, 1000 ft Length, 9.38 Ohm Resistance, Fluoropolymer/Polyolefin Insulation, PVC Jacket, White Jacket, -20 to 79 deg C
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size24 AWG
Conductor TypeAnnealed Bare Solid Copper
Country of OriginUS
Insulation MaterialFluoropolymer/Polyolefin
Jacket ColorWhite
Jacket MaterialPVC
ManufacturerPrysmian
Number of Conductors4 Pairs
Outside Diameter0.18 in
Package TypePull-Pac
Resistance9.38 Ohm
SeriesPull-PacĀ® II
Temperature Rating-20 to 79 deg C
TypeCMP UTP Cat 5e Plenum
Documents
Applications
IEEE 802.3: 1000 BASE-T (Gigabit Ethernet), 100 BASE-TX, 10 BASE-T 52/155 Mp/s ATM ANSI X3.263: 100 Mb/s EEE 802.3af for DTE Power (PoE) EEE 802.3at for PoE Plus Broadband and Baseband Analog Video Applications
Features
- Engineered to provide stable and continuous performance
- Ripcord applied longitudinally under jacket
- TRU-Mark print legend contains footage marking from 1000 to 0 ft
- Third party verified for guaranteed performance
- Performance guaranteed to 200 MHz
- Low smoke, flame-retardant PVC jacket
- Standard compliant extended frequency
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI/TIA-568-C.2|862|NEC/CEC Type CMR|UL 1666|UL 444|ICEA S-90-661|IEC 11801 Ed.2.0 Class D
